The Ulaanbaatar Boot
A friend and I stumbled across these boots in a military antiques shop (now closed) in Seattle. We recognized them as traditional Mongolian footwear, and were informed by the shopkeeper that they are still manufactured for the military in the Mongolian capital city of Ulaanbaatar. When the stitching wore through the soles of the pair I bought, I tore them apart to refurbish them. This article outlines the process for putting them back together again.
Additional pictures of my boots (in their current state of disrepair) can be viewed here.
I also would like to thank Subadai for forwarding me the nice pictoral of other boot styles via the Bata Shoe Museum.
Boot pattern and materials - Warning - these drawings are not to scale!
To draft a pattern for the sole, trace around your foot on a piece of sturdy paper. Add about 3" to the toe, and about 1 1/2" at the heel as shown at left. Add at least 1/2" around all edges of the pattern. Your boot should be large enough to accommodate 1/2" layer of socks. (The pattern for the felt sock that is traditionally worn with this boot is at the end of this article.) You will need 4 sole pieces.
To draft a pattern for the upper boot (or calf section), measure around your calf and add 3 - 4", then divide in half. For instance, my calf measures 14" divided in half equals 7" + 3" = 10". This upper boot pattern is therefore 10" across, 9" at its narrowest point. The upper boot should extend from the top of your foot to the bottom of your kneecap. You will need 4 upper boot sections.
To draft the lower boot (or foot section) cut a piece as shown at left. The measurements and curves should match your calf and sole pieces. I recommend that you cut your pattern out of tag board and tape the pieces together to make sure that they will assemble correctly, before cutting in to your leather. You will need 4 lower boot sections.
To determine the amount of leather you will need, lay out your pattern pieces and measure the square footage. In addition to the leather, you will need:
- sole leather
- stamped shoe weight leather
- glove weight leather strips for piping
- glove weight leather for appliquéd cutwork and top facing (optional but recommended)
- colored fabric scraps for the back of the appliquéd cutwork (optional)
- single fold bias tape
- thick felt for insoles
- cotton or linen to cover the insoles
- sinew for stitching the boots together
- composite soles (optional but highly recommended)
Assemble the soles
Cut 2 soles of yak or sole leather. These will be your outer soles.
Cut 2 soles of stamped or thin, sturdy leather. These will be your inner soles.
The appearance of a stacked leather sole is accomplished by stacking 9 layers of single fold cotton bias tape seam binding (white or tan) around the outer edge of the inner sole. I replaced the bottom layer of seam binding with single fold suede leather and stitched it down. I stitched each layer of seam binding down separately over the leather, rather than trying to stitch through all 8 layers at once. The top 2 layers are turquoise leather, the same type that is used as piping throughout the rest of the boot. Seam binding and soft leathers are used because they shrinks tight when they get wet, making a weather-resistant seam.
The pattern for the insole pad may need to be cut down so that it fits inside of the stacked seam binding. Cut 2 insoles from 1/4" felt. Cut 2 insole covers out of cotton or linen, allowing 1/2" seam allowance. Turn the seam allowance over the edge of the felt and baste the edges to the underside of the insole. Place the covered insole on the inner sole; it should sit a little lower than the stacked bindings. Using sinew, whip stitch the insole to the inner sole so that it stays in place. The whip stitch pattern is indicated in the figure pictured here.
Assemble the upper boot
Cut the foot and calf pieces out of stamped shoe weight leather. If you want to embellish your boots, appliqué these pieces now, using your glove leather and fabric pieces. The photo shows a piece of appliqué at the top of the boot, an orange stripe, and another piece of appliqué above that. The orange stripe is the top of the boot, the appliqué above it belongs to a separate sock.. The orange stripe is a facing that is applied to the boot to finish the top edge. The appliqués at the heel and toe help to stiffen and reinforce those areas. The edges of the appliqué extend to the edge of the leather piece, and are stitched in to the seams, again as a method of reinforcement. The photo shows turquoise leather used as the background for the appliqués; my boots have red and yellow fabric incorporated as backgrounds in addition to the turquoise leather. I have also seen brocades used as background color for these appliqués.
Match the bottom of the calf section to the top of the foot section. Insert 3 layers of single fold (turquoise) leather between the foot and calf pieces, matching all raw edges. Stitch these sections together using 1/4" seam allowance. Stitch each foot / calf section together at the front and back, again using 3 layers of single fold (turquoise) leather as piping.
The orange leather (as shown in the photograph) is the same weight as the appliqué leather. Place the right side of the leather on the inside of the boot and stitch it across the top. Fold this leather to the outside and stitch it down on the front of the boot. This is a typical Chinese textile facings; and covers the raw edge of the top of the boot.
Cut out 2 pear shaped tabs of stamped leather. Stitch the top of the pear to the back seam of the calf section, inside the boot, to cover the intersecting seams. This piece of leather hangs over the seams and protects your sock from wearing through at the heel. It will conform to your foot and should not need to be stitched down anywhere else.
Bringing sole to your boot
Sew the inner sole to the foot of the boot, starting at a side. DO NOT start at the ankle or the toe if you are doing this by hand.
The outer sole on the original boot was sewn on at the same time as the inner sole.. The original outer sole was sliced diagonally along the running stitches, to conceal and protect them. As the outer sole wore away, the stitches became exposed and broke, which caused the entire sole to come away from the boot. After attempting to sew through the outer sole, inner sole and multiple layers of bindings, I gave up and glued the outer sole on. Regardless of whether you stitch or glue your outer sole on, I heartily recommend that you glue an additional outer sole, preferably of a composite material, to the bottom of the outer sole. The Ulaanbaatar boot is designed for walking on grass and tundra, rather than the concrete and gravel that many of us are subject to. A composite sole (rubber or other man made material) will help to protect your handiwork and will preserve the life of your boot.
The only problem I have encountered in putting these boots together is that the toe tends to splay. My boots originally had a single stitch at the toe which prevented the layers from separating, but I haven't figured out how to do it. My husband put a screw into the toe, which works, as long as I don't kick anything...
Sock pattern and materials
The sock works best if it is made of 1/4" or 1/2" thick felt. If you are not a felt maker, quilt several pieces of wool felt or woven wool together. Do not use Poly Craft Felt, as it will shred after only a few wearings. My husband's boots had a quilted cotton sock which does not work as well because it falls down inside the boot. I sewed ribbons to the top edges of his socks, just below the appliqué band at the top, which tied to the top of the boot, which kept them in place when he wore them. Your socks will work best if they are sturdy enough to stand by themselves in order to support the appliqué at the top, and to stay in place inside the boot.
To draft the sole of the sock, trace around your foot and add 1" at the heel, and 2" at the toe. The seam allowances on the original sock are 1/4", I suspect that they used 1/2" and then trimmed the seams down. The sock still has a pointed toe but it is not a severe of a point as the boot. Cut 2 soles.
To draft the upper sock, add 1 - 2" to your calf measurement. Standing on the floor, measure from the floor to the center of your knee to determine the height of your sock. The upper sock attaches directly to the sole, so there is no "foot" piece as there is in the boot. Cut 2 calf sections, on the fold of your material.
The heel section of my sock measures 5 1/2" tall, 1" at the top and about 3 1/2" at the bottom. bottom. Cut 2 pieces, one for each sock.
The toe section measures 7" tall by 5 1/2" at its widest point. Cut 4 pieces. Sew 2 pieces together along the top curve.
Assemble the sock
Cut the upper sock so that the straight front line is on the fold of your felt. The band at the top of this pattern is where your appliqué work should be placed. This band of appliqué is about 4" tall and is executed in glove leather. The top edge is faced with bias cut corduroy. The bottom edge of the appliqué work is finished with a piece of fabric or leather piping. Do the appliqué work before assembling the rest of the sock.
Both the heel and toe are sewn into this section as gussets, again allowing for 1/2" seam allowances. Slit the front fold to accommodate the toe gusset. Sew the heel gusset onto the back of the calf section. Sew the back of the sock halfway, which will leave a 1/2" wide slit, half way down the back of the sock. On my sock these edges are whip stitched, and there is no other decorative treatment, facing or finishing.
Trim all seams to 1/4". You will want to reinforce the heel with denim or other firmly woven cloth, as I found mine very prone to wear.
